IE2 High Efficiency Induction Electric Motor

Low-voltage motors

This kind of motor is widely used in polisher, burnisher and glass machinery manufacturing companies.

E-mail

Message

Description

Induction Electric Motor Technical characteristics

l Totally enclosed fan-cooled motors are designed according to IEC, GB and other standards.

l The frames are made of cast iron, while terminal boxes can be made of steel plate.

l The efficiency can meet the requirements of GB18613-2013 and IEC60034-30 standards.

l Standard Motors with frame 80-132 that are equipped with gasket sealing on DE are standard, and the standard for frame 160 and above motors are with sealing on DE.

l Winding designs can support several kinds of voltage and frequency (50HZ or 60HZ).

l It can stand 1.5 times more of rated current within 2 minutes (IEC60034-1).

l Heater can be added to prevent moisture.

l PTC, PT100 and other thermal elements can be chose to protect winding and bearings.

Standard induction motor Product advantages

l Efficiency improvement

New winding designs and low loss silicon steel sheets are applied to decrease the motors loss and improve the efficiency.

l Reliable quality and superior characteristics

In order to insure the good insulation and extend the lifetime, standard motors are examined with F insulation and 80K temperature-rise.

l Voltage, Efficiency

According to Class A voltage and frequency tolerance demands in IEC60034-1 standard, the motor’s voltage tolerance is ±5%, and the frequency tolerance is ±2%.

l Rated output

Rated output means it can meet IEC 600341-1 standard, continuous working can output when coolant temperature (CT) is 40℃ and the altitude of working site is under 1000m. Besides, the motors can stand 1.5 times more of rated current within 2 minutes under rated voltage and frequency.

Standard induction motor application

Standard induction Motors can be applied to all kinds of machines, such as machine tool, air compressor, pump, ventilation, reduction gear, transmission belt, mining equipment, metallic equipment. However, motors can’t be used with inflammable, explosive and corrosive working site.

Standard induction motor electrical performance data

MotorType	Rated Power (kW)	Rated Speed(RPM)	Vtltage (V)	Current(A)	Start current tatio (%)	Torque (%)	Max. torque (%)	Efficiency (%)	Power Factor	Moment of intertia(J) (kg.m-2)	Approx WT(kg)
IE2-80K2	0.75	2845	230	2.9	700	220	230	77.4	0.83	0.0011	17
IE2-80G2	1.1	2845	230	4.2	740	220	230	79.6	0.83	0.0013	18
IE2-80G4	0.75	1415	230	3.4	650	230	230	79.6	0.7	0.0017	19
IE2-90S2	1.5	2875	230	5.6	700	220	230	81.3	0.83	0.0019	23
IE2-90L2	2.2	2865	230	8.0	700	220	230	83.2	0.83	0.0022	26
IE2-90S4	1.1	1410	230	4.8	650	230	230	81.4	0.7	0.0021	23
IE2-90L4	1.5	1420	230	6.3	710	250	280	82.8	0.72	0.0027	29
IE2-90S6	0.75	925	230	3.4	550	200	230	75.9	0.72	0.0032	24
IE2-90L6	1.1	920	230	4.8	550	200	230	78.1	0.73	0.0041	26
IE2-100L2	3	2860	400	5.9	750	220	250	84.6	0.87	0.0043	34
IE2-100L4	2.2	1420	230	8.2	710	250	280	84.3	0.8	0.0054	35
IE2-100LX4	3	1440	400	6.5	780	250	280	85.5	0.78	0.0067	39
IE2-100L6	1.5	930	230	6.5	550	200	220	79.8	0.73	0.0085	34
IE2-112M2	4	2880	400	7.6	750	220	250	85.8	0.88	0.0065	41
IE2-112M4	4	1445	400	8.5	750	250	280	86.6	0.78	0.0086	46
IE2-112M6	2.2	945	230	8.9	650	210	220	81.8	0.76	0.0133	40
IE2-132S2	5.5	2925	400	10.4	750	220	250	87	0.88	0.0146	63
IE2-132SX2	7.5	2930	400	15.8	750	220	250	88.1	0.88	0.0157	68
IE2-132S4	5.5	1460	400	11.9	720	250	280	87.7	0.8	0.0205	68
IE2-132M4	7.5	1450	400	15.3	720	250	280	88.7	0.8	0.0296	80
IE2-132S6	3	965	400	6.8	650	210	250	83.3	0.76	0.0372	60
IE2-132M6	4	965	400	9.0	650	210	250	84.6	0.76	0.0489	77
IE2-132MX6	5.5	965	400	12.0	650	200	250	86	0.77	0.0585	81
IE2-160M2	11	2935	400	20.0	750	220	250	89.4	0.89	0.0549	113
IE2-160MX2	15	2935	400	26.9	750	220	250	90.3	0.89	0.0635	123
IE2-160L2	18.5	2935	400	32.6	750	220	250	90.9	0.9	0.0725	141
IE2-160M4	11	1455	400	21.3	760	210	280	89.8	0.83	0.0724	125
IE2-160L4	15	1465	400	28.1	690	210	280	90.6	0.85	0.0929	146
IE2-160M6	7.5	970	400	16.8	650	200	230	87.2	0.74	0.1212	114
IE2-160L6	11	970	400	23.6	640	200	230	88.7	0.76	0.1452	135
IE2-180M2	22	2950	400	38.6	750	220	250	91.3	0.9	0.1025	180
IE2-180M4	18.5	1470	400	34.4	750	210	280	91.2	0.85	0.1350	179
IE2-180L4	22	1470	400	40.8	750	210	280	91.6	0.85	0.1360	195
IE2-180L6	15	975	400	30.6	700	210	230	89.7	0.79	0.2285	185
IE2-200L2	30	2950	400	52.9	750	200	220	92	0.89	0.1730	232
IE2-200LX2	37	2950	400	65.6	750	200	230	92.5	0.88	0.1950	246
IE2-200L4	30	1465	400	54.6	710	180	280	92.3	0.86	0.2450	248
IE2-200L6	18.5	980	400	37.4	700	210	240	90.4	0.79	0.3420	252
IE2-200LX6	22	980	400	43.1	700	210	240	90.9	0.81	0.3860	310
IE2-225M2	45	2960	400	77.7	750	200	230	92.9	0.9	0.3250	315
IE2-225S4	37	1470	400	68.6	660	180	280	92.7	0.84	0.3900	304
IE2-225M4	45	1475	400	83.1	660	180	280	93.1	0.84	0.4500	337
IE2-225M6	30	980	400	57.6	700	200	230	91.7	0.82	0.6250	303
IE2-250M2	55	2970	400	96.8	750	200	230	93.2	0.88	0.3950	390
IE2-250M4	55	1475	400	99.9	660	210	280	93.5	0.85	0.6400	395
IE2-250M6	37	980	400	69.0	700	210	250	92.2	0.84	0.9850	405
IE2-280S2	75	2970	400	132.7	750	200	230	93.8	0.87	0.6830	540
IE2-280M2	90	2975	400	158.7	750	200	230	94.1	0.87	0.7650	570
IE2-280S4	75	1480	400	130.9	760	210	280	94	0.88	1.0450	600
IE2-280M4	90	1485	400	155.0	710	210	280	94.2	0.89	1.3960	660
IE2-280S6	45	985	400	84.4	700	210	250	92.7	0.83	1.7320	465
IE2-280M6	55	985	400	102.7	700	210	250	93.1	0.83	1.9650	540
IE2-315S2	110	2975	400	187.1	710	180	230	94.3	0.9	1.5580	960
IE2-315M2	132	2975	400	223.8	710	180	220	94.6	0.9	1.7260	1010
IE2-315L2	160	2980	400	273.7	710	180	220	94.8	0.89	1.9410	1120
IE2-315LX2	200	2985	400	337.6	710	180	220	95	0.9	2.2120	1200
IE2-315S4	110	1485	400	195.4	710	210	220	94.5	0.86	3.4800	960
IE2-315M4	132	1485	400	228.6	690	210	220	94.7	0.88	3.6780	1040
IE2-315L4	160	1485	400	279.7	690	210	220	94.9	0.87	4.4720	1140
IE2-315LX4	200	1485	400	348.9	690	210	220	95.1	0.87	4.8560	1250
IE2-315S6	75	985	400	135.9	700	200	220	93.7	0.85	3.7230	900
IE2-315M6	90	985	400	160.7	700	200	220	94	0.86	4.5260	980
IE2-315L6	110	985	400	195.8	670	200	220	94.3	0.86	5.1570	1160
IE2-315LX6	132	985	400	236.9	670	200	220	94.6	0.85	5.6850	1210
IE2-355M2	250	2985	400	426.8	710	160	220	95	0.89	3.8490	1760
IE2-355L2	280	2990	400	472.7	710	160	220	95	0.9	3.9490	1870
IE2-355LX2	315	2990	400	531.8	710	160	220	95	0.9	3.9950	1920
IE2-355LY2	355	2990	400	592.7	750	140	200	95	0.91	4.1250	1975
IE2-355M4	250	1485	400	426.3	690	210	220	95.1	0.89	7.3640	1740
IE2-355L4	280	1490	400	477.5	710	210	220	95.1	0.89	8.0140	1830
IE2-355LX4	315	1490	400	531.2	690	210	220	95.1	0.9	9.1000	1975
IE2-355LY4	355	1490	400	598.7	690	210	220	95.1	0.9	9.6000	2148
IE2-355M6	160	990	400	283.3	670	190	200	94.8	0.86	9.5700	1770
IE2-355L6	200	990	400	353.3	670	190	200	95	0.86	9.8900	1870
IE2-355LX6	250	990	400	436.6	670	190	200	95	0.87	11.1000	1900
IE2-355LY6	280	990	400	483.4	670	190	200	95	0.88	11.3000	1980

Standard induction motor mechanical dimension data

B3：Dimension Drawings

The shaft dimension will be showed in anther table

Frame	Pole	Mounting dimension						Overall dimension
		A	B	B1	C	H	K	AA	AB	AC	AD	BB	HA	HB	HD		L	LD
		A	B	B1	C	H	K	AA	AB	AC	AD	BB	HA	HB	top	left/right	L	LD
80	2-8	125	100	-	50	80°-0.5	10	35	160	160	145	130	12	36	225	160	280	75
90S	2-8	140	100	-	56	90°-0.5	10	36	180	180	155	140	12	50	245	180	335	75
90L	2-8	140	125	-	56	90°-0.5	10	36	180	180	155	165	12	50	245	180	360	75
100L	2-8	160	140	-	63	100°-0.5	12	40	200	200	180	175	14	55	280	200	395	83
112M	2-8	190	140	-	70	112°-0.5	12	45	230	220	190	180	15	60	305	222	420	87
132S	2-8	216	140	-	89	132°-0.5	12	55	265	260	220	190	18	65	355	262	465	102
132M	2-8	216	178	-	89	132°-0.5	12	55	265	260	220	230	18	65	355	262	505	102
160M	2-8	254	210	-	108	160°-0.5	15	65	315	315	265	260	20	81	425	385	608	146
160L	2-8	254	254	-	108	160°-0.5	15	65	315	315	265	305	20	81	425	385	652	146
180M	2.4	279	241	-	121	180°-0.5	15	70	350	360	280	315	22	105	460	420	690	161
180L	4-8	279	279	-	121	180°-0.5	15	70	350	360	280	350	22	105	460	420	730	161
200L	2-8	318	305	-	133	200°-0.5	19	70	390	400	310	370	25	85	510	475	760	186
225S	4-8	356	286	-	149	225°-0.5	19	75	435	450	335	370	28	110	555	535	810	189
225M	2	356	311	-	149	225°-0.5	19	75	435	450	335	395	28	110	555	535	805	189
225M	4-8	356	311	-	149	225°-0.5	19	75	435	450	335	395	28	110	555	535	835	189
250M	2	406	349	-	168	250°-0.5	24	80	485	485	375	445	30	110	625	570	910	207
250M	4-8	406	349	-	168	250°-0.5	24	80	485	485	375	445	30	120	625	570	910	207
280S	2	457	368	-	190	280°-1.0	24	85	545	550	405	490	35	142	685	660	985	215
280S	4-8	457	368	-	190	280°-1.0	24	85	545	550	405	490	35	142	685	660	1005	215
280M	2	457	419	-	190	280°-1.0	24	85	545	550	405	540	35	142	685	660	1030	215
280M	4-8	457	419	-	190	280°-1.0	24	85	545	550	405	540	35	142	685	660	1060	215
315S	2	508	406	-	216	315°-1.0	28	120	630	625	530	570	45	110	845	750	1180	257
315S	4-8	508	406	-	216	315°-1.0	28	120	630	625	530	570	45	110	845	750	1210	257
315M	2	508	457	508	216	315°-1.0	28	120	630	625	530	680	45	110	845	750	1290	257
315L	4-8	508	457	508	216	315°-1.0	28	120	630	625	530	680	45	110	845	750	1320	257
355	2	610	560	630	254	355°-1.0	28	120	730	700	615	750	52	110	970	810	1526	284
355	4-8	610	560	630	254	355°-1.0	28	120	730	700	615	750	52	110	970	810	1556	284

B35：Dimension Drawings
The shaft dimension will be showed in anther table

Frame	Pole	Mounting dimension												Overall dimension
		A	B	B1	C	H	K	M	N	P	R	S	T	AA	AB	AC	AD	BB	HA	HB	HD		L	LA	LD
		A	B	B1	C	H	K	M	N	P	R	S	T	AA	AB	AC	AD	BB	HA	HB	上出线	左右出线	L	LA	LD
80	2-8	125	100	-	50	80°-0.5	10	165	130	200	0	4-Φ12	4	35	160	160	145	130	12	36	225	160	280	12	75
90S	2-8	140	100	-	56	90°-0.5	10	165	130	200	0	4-Φ12	4	36	180	180	155	140	12	50	245	180	335	12	75
90L	2-8	140	125	-	56	90°-0.5	10	165	130	200	0	4-Φ12	4	36	180	180	155	165	12	50	245	180	360	12	75
100L	2-8	160	140	-	63	100°-0.5	12	215	180	250	0	4-Φ15	4	40	200	200	180	175	14	55	280	200	395	13	83
112M	2-8	190	140	-	70	112°-0.5	12	215	180	250	0	4-Φ15	4	45	230	220	190	180	15	60	305	222	420	14	87
132S	2-8	216	140	-	89	132°-0.5	12	265	230	300	0	4-Φ15	4	55	265	260	220	190	18	65	355	262	465	14	102
132M	2-8	216	178	-	89	132°-0.5	12	265	230	300	0	4-Φ15	4	55	265	260	220	230	18	65	355	262	505	14	102
160M	2-8	254	210	-	108	160°-0.5	15	300	250	350	0	4-Φ19	5	65	315	315	265	260	20	81	425	385	608	15	146
160L	2-8	254	254	-	108	160°-0.5	15	300	250	350	0	4-Φ19	5	65	315	315	265	305	20	81	425	385	652	15	146
180M	2.4	279	241	-	121	180°-0.5	15	300	250	350	0	4-Φ19	5	70	350	360	280	315	22	105	460	420	690	15	161
180L	4-8	279	279	-	121	180°-0.5	15	300	250	350	0	4-Φ19	5	70	350	360	280	350	22	105	460	420	730	15	161
200L	2-8	318	305	-	133	200°-0.5	19	350	300	400	0	4-Φ19	5	70	390	400	310	370	25	85	510	475	760	17	186
225S	4-8	356	286	-	149	225°-0.5	19	400	350	450	0	8-Φ19	5	75	435	450	335	370	28	110	555	535	810	20	189
225M	2	356	311	-	149	225°-0.5	19	400	350	450	0	8-Φ19	5	75	435	450	335	395	28	110	555	535	805	20	189
225M	4-8	356	311	-	149	225°-0.5	19	400	350	450	0	8-Φ19	5	75	435	450	335	395	28	110	555	535	835	20	189
250M	2	406	349	-	168	250°-0.5	24	500	450	550	0	8-Φ19	5	80	485	485	375	445	30	110	625	570	910	22	207
250M	4-8	406	349	-	168	250°-0.5	24	500	450	550	0	8-Φ19	5	80	485	485	375	445	30	120	625	570	910	22	207
280S	2	457	368	-	190	280°-0.1	24	500	450	550	0	8-Φ19	5	85	545	550	405	490	35	142	685	660	985	22	215
280S	4-8	457	368	-	190	280°-0.1	24	500	450	550	0	8-Φ19	5	85	545	550	405	490	35	142	685	660	1005	22	215
280M	2	457	419	-	190	280°-0.1	24	500	450	550	0	8-Φ19	5	85	545	550	405	540	35	142	685	660	1030	22	215
280M	4-8	457	419	-	190	280°-0.1	24	500	450	550	0	8-Φ19	5	85	545	550	405	540	35	142	685	660	1060	22	215
315S	2	508	406	-	216	315°-0.1	28	600	550	660	0	8-Φ24	6	120	630	625	530	570	45	110	845	750	1180	22	257
315S	4-8	508	406	-	216	315°-0.1	28	600	550	660	0	8-Φ24	6	120	630	625	530	570	45	110	845	750	1210	22	257
315M	2	508	457	508	216	315°-0.1	28	600	550	660	0	8-Φ24	6	120	630	625	530	680	45	110	845	750	1290	22	257
315L	4-8	508	457	508	216	315°-0.1	28	600	550	660	0	8-Φ24	6	120	630	625	530	680	45	110	845	750	1320	22	257
355	2	610	560	630	254	355°-0.1	28	740	680	800	0	8-Φ24	6	120	730	700	615	750	52	125	970	830	1526	25	284
355	4-8	610	560	630	254	355°-0.1	28	740	680	800	0	8-Φ24	6	120	730	700	615	750	52	125	970	830	1556	25	284

Shaft Dimension Drawings

Frame	Pole	D	E	F	G	GD	DB
80	2、4、6、8	19j6(+0.009 -0.004)	40	6	15.5	6	M6
90S	2、4、6、8	24j6(+0.009 -0.004)	50	8	20	7	M8
90L	2、4、6、8	24j6(+0.009 -0.004)	50		20		M8
100L	2、4、6、8	28j6(+0.009 -0.004)	60		24		M10
112M	2、4、6、8	28j6(+0.009 -0.004)	60		24		M10
132S	2、4、6、8	38k6(+0.018 -0.002)	80	10	33	8	M12
132M	2、4、6、8	38k6(+0.018 -0.002)	80	10	33		M12
160M	2、4、6、8	42k6(+0.018 -0.002)	110	12	37		M16
160L	2、4、6、8	42k6(+0.018 -0.002)		12	37
180M	2.4	48k6(+0.018 -0.002)		14	42.5	9
180L	4、6、8	48k6(+0.018 -0.002)		14	42.5	9
200L	2	55m6(+0.03 -0.011)		16	49	10	M20
200L	4、6、8	55m6(+0.03 -0.011)		16	49	10
225S	4、6、8	60m6(+0.03 -0.011)	140	18	53	11
225M	2	55m6(+0.03 -0.011)	110	16	49	10
225M	4、6、8	60m6(+0.03 -0.011)	140	18	53	11
250M	2	60m6(+0.03 -0.011)			53	11
250M	4、6、8	65m6(+0.03 -0.011)			58	11
280S	2	65m6(+0.03 -0.011)			58	11
280S	4、6、8	75m6(+0.03 -0.011)		20	67.5	12
280M	2	65m6(+0.03 -0.011)		18	58	11
280M	4、6、8	75m6(+0.03 -0.011)		20	67.5	12
315S	2	65m6(+0.03 -0.011)	140	18	58	11
315S	4、6、8	80m6(+0.03 -0.011)	170	22	71	14
315M315L	2	65m6(+0.03 -0.011)	140	18	58	11
315M315L	4、6、8	80m6(+0.03 -0.011)	170	22	71	14
355	2	75m6(+0.03 -0.011)	140	20	67.5	12
355	4、6、8	95m6(+0.035 -0.013)	170	25	86	14
